Alstam HRSG Duct Burners
Alstam designs and manufactures complete N.G. fired duct burner assemblies for HRSG and air-heater applications. Each system is engineered for even flow, stable combustion, high turndown, and dependable operation across a wide range of conditions. Our three stabilizer options, the Alstam Standard Design (ASTD), High-Capacity (HC), and High-Capacity Extra (HCX) allow us to match the burner configuration to your system’s performance needs.
Alstam Products
ASTD
- Self-supporting up to 36’
- Up to 3 MMBTU/hr heat release per linear foot
HC
- Self-supporting up to 16’ (HC)
- Up to 6 MMBTU/hr heat release per linear foot
- With higher heat release, less elements are needed per duct burner assembly
- Split bluff body design allows for unique aeration, more precise control of the fuel/air mixing for optimized combustion, and shorter flame lengths
HCX
- Self-supporting up to 36' (HCX)
- Up to 6 MMBTU/hr heat release per linear foot
- With higher heat release, less elements are needed per duct burner assembly
- Split bluff body design allows for unique aeration, more precise control of the fuel/air mixing for optimized combustion, and shorter flame lengths
Product Details
DUCT BURNERS:
- Alstam offers a line of cost effective duct burner standard designs.
- Combustion Turbine flows from 40,000 pph to 4,000,000 pph
- Oxygen Content down to 12 % by volume
- Water content to 15% without augmenting air
- Turndown up to 15:1
- Low NOx and CO emissions
- Meets NFPA, CSA, all other codes
VALVE RACK:
- Complies with ANSI B31.1
- Carbon Steel Valve Assemblies
- Easy access for maintenance
BURNER MANAGEMENT SYSTEMS:
- PLC Based single and multiple element operation
- HMI
- Meets NFPA
